Procemex Flex Full HD Smart Camera 2.1MP B&W
High definition, fast and extremely light sensitive camera suitable for inspecting and filming all pulp and paper grades and printed products with 2040×1020 pixel resolution, 900 fps.
Procemex Procemex Flex Full HD B&W camera has superior performance with resolution, light sensitivity and speed for all applications.
The camera has been specifically designed by Procemex engineers to meet the demands of fast paper and printing machines, with existing systems running beyond 2000 m/min (6500 ft/min). It is ideal for providing compromise free web inspection on slitter winders reaching up to 3000 m/min (9800 ft/min) speed.
It can be used in all machine sections from forming section through dryer positions to the reel of paper machines. It can also be applied in various printing applications not requiring color.
- Fastest and most accurate smart cameras
- All applications can utilize the same camera
- True smart cameras with compact packaging
- Future proof CMOS based image sensor design – easy upgrade when needed
- PC-and TCP/IP network compatible
- Performance (resolution, frame rate, special application features) software selectable
- Processed data in FIFO RAM buffer
- Both FPGA and DSP –based real-time data processing
- Strobe LED light controlling
- Standard C-mount fixed lens, zoom lens or pinhole lens
- Power over Ethernet (PoE) for WIS applications
- Flicker and fade in-fade out -free images with 24 VAC ambient light power cycle
Key Features
|
Specification
- 2.1 Megapixels (2040×1020)
- 900 frames per second
- 12 GOPS (Gigaoperations per second)
- Smallest size in the market (W91 mm x H69mm x D165 mm without lens)
